SDRAIL PRO RAILING
Railings
The safety railings of the SDRAIL PRO line are made of 6060 T6 aluminium alloy and guarantee a safe working environment, especially in those areas subject to frequent maintenance and checks that present the risk of falling from a height.
The fall protection railings are designed to allow easy and quick installation in spaces subject to the risk of falling from a height, for roofing inclined up to a maximum of 15°. Each bearing element of the railings is made with extruded profiles in light alloy, calculated and certified to ensure the maximum strength/lightness ratio, in accordance with the strength and stiffness values prescribed by current regulations. The material used also allows excellent resistance to atmospheric agents in addition to the ease of transport, due to low weights.
The fall protection railing can be adapted to countless geometries and profiles of the edge of the installation roof, thanks to the use of fixing accessories made by Sicur Delta.
![](https://sicurdelta.it/app/uploads/2022/02/parapetto-parete-dritto.jpg)
STRAIGHT PILLAR
Fixing the bases of the wall pillar on vertical surfaces (internal or external to the edge of the roof) of the load-bearing structures.
It can be installed on roofs with surface filling thicknesses up to 500 mm. The wheelbase will be adapted accordingly, in relation to the different height of the pillar.
Possibility to choose between straight or curved pillar.
![](https://sicurdelta.it/app/uploads/2022/02/parapetto-parete-curvo.jpg)
CURVED PILLAR
Fixing the bases of the wall pillar on vertical surfaces (internal or external to the edge of the roof) of the load-bearing structures.
It can be installed on roofs with surface filling thicknesses up to 500 mm. The wheelbase will be adapted accordingly, in relation to the different height of the pillar.
Possibility to choose between straight or curved pillar.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-dritto-fissaggio-a-parete-ribaltabile-1000x1000.jpg)
Folding wall fastening
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-dritto-fissaggio-a-pavimento-Sdrail-Pro-1-1000x1000.png)
STRAIGHT PILLAR
Fixing the bases of the pillars on horizontal load-bearing surfaces.
Possibility to choose between straight or curved pillar.
Possibility of tilting floor configuration.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-curvo-fissato-a-pavimento-REV02-Sdrail-Pro-1000x1000.jpg)
CURVED PILLAR
Fixing the bases of the pillars on horizontal load-bearing surfaces.
Possibility to choose between straight or curved pillar.
Possibility of tilting floor configuration.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-dritto-fissaggio-a-pavimento-ribaltabile-1000x1000.jpg)
Folding floor fixing
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-autoportante-2-zavorre-montante-dritto-Sdrail-Pro-1000x1000.png)
UNI 14122-3:2016 STRAIGHT PILLAR
Positioning of the bases of the pillars on horizontal surfaces of load-bearing structures when there is a need or desire not to drill or a temporary installation is required.
Establish the suitability of the capacity of the floor for the application of the load and consider the spaces necessary for the positioning of the ballasts according to regulations (2 if compliant with UNI 14122-3:2016 or 6 if NTC-2018).Possibility to choose between straight or curved pillar.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-autoportante-2-zavorre-montante-curvo-Sdrail-Pro-1000x1000.png)
UNI 14122-3:2016 CURVED PILLAR
Positioning of the bases of the pillars on horizontal surfaces of load-bearing structures when there is a need or desire not to drill or a temporary installation is required.
Establish the suitability of the capacity of the floor for the application of the load and consider the spaces necessary for the positioning of the ballasts according to regulations (2 if compliant with UNI 14122-3:2016 or 6 if NTC-2018).Possibility to choose between straight or curved pillar.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-autoportante-con-6-zavorre-montante-dritto-Sdrail-Pro-1000x1000.png)
NTC-2018 STRAIGHT PILLAR
Positioning of the bases of the pillars on horizontal surfaces of load-bearing structures when there is a need or desire not to drill or a temporary installation is required.
Establish the suitability of the capacity of the floor for the application of the load and consider the spaces necessary for the positioning of the ballasts according to regulations (2 if compliant with UNI 14122-3:2016 or 6 if NTC-2018).
Possibility to choose between straight or curved pillar.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-autoportante-con-6-zavorre-montante-curvo-Sdrail-Pro-1000x1000.png)
NTC-2018 CURVED PILLAR
Positioning of the bases of the pillars on horizontal surfaces of load-bearing structures when there is a need or desire not to drill or a temporary installation is required.
Establish the suitability of the capacity of the floor for the application of the load and consider the spaces necessary for the positioning of the ballasts according to regulations (2 if compliant with UNI 14122-3:2016 or 6 if NTC-2018).
Possibility to choose between straight or curved pillar.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-autoportante-ribaltabile-1000x1000.jpg)
Folding self-bearing type
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-Sdrail-PRO-lamiera-PE-1000x1000.jpg)
RAILS PERPENDICULAR TO THE CORRUGATIONS
Fixing the bases of the pillars with the appropriate plates on the underlying corrugated sheet (both sandwich panel and single sheet) by means of rivets.
There are two types of pillar bases for corrugated sheet metal depending on the direction of the corrugations: perpendicular or parallel to the rails of the railing.Consider minimum thicknesses of the corrugated sheet.
Possibility to choose between straight or curved pillar.
Possibility of tilting configuration on sheet metal.
![](https://sicurdelta.it/app/uploads/2024/02/Parapetto-Sdrail-PRO-lamiera-PA-1000x1000.jpg)
RAILS PARALLEL TO THE CORRUGATIONS
Fixing the bases of the pillars with the appropriate plates on the underlying corrugated sheet (both sandwich panel and single sheet) by means of rivets.
There are two types of pillar bases for corrugated sheet metal depending on the direction of the corrugations: perpendicular or parallel to the rails of the railing.Consider minimum thicknesses of the corrugated sheet.
Possibility to choose between straight or curved pillar.
Possibility of tilting configuration on sheet metal.
